Plug Valve

Plug Valve

Technology specification：

The design meets the requirement of API SPEC 6A.

Nominal bore：1″~3″

Rated working pressure：6000~15000PSI

Rated working temp：K、L、P、R、S、T、U、V

Material class：AA, BB, CC, DD, EE、FF

Product specification level：PSL1~PSL4

Performance requirement level：PR1

Suitable medium：Petroleum, Natural gas, Mud、The Cementing、Fracturing Etc.

▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂▂

Plug valve is low torque plug valve, which is produced according to SPM technology. The valve body is forged by high-quality alloy steel, specification: 1", 2", 3", rated working pressure 42MPa, 70MPa, 105MPa (6000, 10000, 15000psi).

◆ The two ends can be connected by union joint;

◆ The maintenance of valve body is convenient;

◆ Through plating process, the plug has excellent seal property and anti-corrosive property;

◆ Visible valve body position;

◆ 3″plug valve is suitable for low temperature environment。
